DESIGN : ASME B16.34
VALVE SIZE : 1/2" to 14" (15 to 300mm)
RATING : 150# to 2500# ANSI.(Other Rating Available On Request)
END CONNECTION : Flanged, Screwed, Buttweld, Socketweld
MATERIAL : Carbon steel, Stainless Steel, Alloy Steel, PP, Tefon lined etc.(Other Material Available On Request)
BONNET : Standard, Extended Finned Bonnet, Bellow Sealed.
TRIM FORMS : Top guided Contoured, Micro flow needle. V-Ported (Balanced/Unbalanced), Low Noise Trim.
TRIM MATERIAL : Stainless Steel, Alloy Steel, Stellited. (Other Material Available On Request)
FLOW CHAR : Equal Percentage, Linear and On/Off
SEAT LEAKAGE : Class III, IV, V, & VI (FCI-70.2) Standard Leakage Rates. Metal to Metal Seating Class IV-less than 0.01% of rated Cv. Metal to soft Seating Class VI-Bubble tight (Zero Leakage).
GLAND PACKING : Grafoil or PTFE, Double Gland,(As Per Temperature)
ACTUATOR : Pneumatic Diaphragm, Pneumatic Piston or Electrical.
ACCESSORIES : Pneumatic Positioner, Electro Pneumatic Positioner, Limit Switch, SOV, Volume Booster, AFR, Position Transmitter, Air lock relay, IP Converter.
High flow capacity and rangeability.
Top opening for easy trim inspection without disturbing insulation or piping connections.
Positive guiding for correct trim alignment under all operating conditions.
Wide selection of actuators to meet most system requirements.
Accessories mounting -verity of access like valve positioner, Solenoid valve, Air filter
regulator, Volume booster, Limit switch, position feedback transmitter, Quick exhaust
valves, IP convertor etc. can be mounted easily.
Material certication available for all major component parts
Full guarantee on design and performance.
All testing performance to the requirements of ASME B16.34.
Tight closing for reliable control even when change in pressure / temperature are sudden and extreme.
Comprehensively designed and tested to ensure its optimum performance for
the tough process parameters specified.
